Battery Capacity % guaranteed under warranty:80
Battery Capacity in kWh:74
Battery Charging Scenario 1 - Charge Time (Mins):180
Battery Charging Scenario 1 - Percentage Change:0-100
Battery Charging Scenario 1 - Power Supply - kW:11
Battery Charging Scenario 2 - Charge Time (Mins):64
Battery Charging Scenario 2 - Percentage Change:0-80
Battery Charging Scenario 2 - Power Supply - kW:80
Battery Charging Scenario 3 - Charge Time (Mins):Not Available
Battery Charging Scenario 3 - Percentage Change:Not Available
Battery Charging Scenario 3 - Power Supply - kW:Not Available
Battery Charging Scenario 4 - Charge Time (Mins):Not Available
Battery Charging Scenario 4 - Percentage Change:Not Available
Battery Charging Scenario 4 - Power Supply - kW:Not Available
Battery Leased:No
Battery Type:Lithium-ion
Charging Port Location:Front
Coupler/Connector Type:Type 2
Maximum Charging Rate - kW:80
Standard manufacturers Battery warranty - Mileage:155000
Standard manufacturers Battery warranty - Years:8
Usable Battery Capacity:70
WLTP - EC (kWh/100km) - Comb:32.2
WLTP - EC (miles/kWh) - Comb:1.9
WLTP - Pure Electric Range (km) - Comb:217
WLTP - Pure Electric Range (miles) - Comb:134.8
CO:Not Available
CO2:Data Not Available
HC:Not Available
HC+NOx:Not Available
Noise Level dB(A):Not Available
NOx:Not Available
Particles:Not Available
Standard Euro Emissions:Not Available
Automatic Transmission:Yes
Bore:Not Available
Catalytic Convertor:Not Available
CC:1
Compression Ratio:Not Available
Cooling System:Not Available
Cylinder Layout:Not Available
Cylinders:Not Available
Engine Codes:Not Available
Engine Layout:Not Available
Engine Make:Not Available
Fuel Delivery:Not Available
Fuel Type:Not Available
Gears:1 SPEED
Manual Transmission:No
Number of Valves:Not Available
Stroke:Not Available
Valve gear:Not Available
EC:Not Available
EC Combined:Not Available
EC Extra Urban:Not Available
EC Urban:Not Available
Alternative Fuel Qualifying:Yes
Did at least one aspect of this vehicles safety give cause for concern?:No
Badge Engine CC:Data Not Available
Badge Power:190
Based On ID:Not Available
Battery AH:105
Battery Volts:12
Chassis Engine Number:Not Available
Clutch:Not Available
Coin Description:Not Available
Coin Gross Vehicle Weight Code:Not Available
Coin Power Output Code:Not Available
Coin Series:Not Available
Coin Wheelbase Description Code:Not Available
Coin Wheelbase Name Code:Not Available
Front Brakes:VENTILATED DISCS
Front Suspension:LEAF SPRINGS
Generation Mark:3
Ghost model for valuation purposes:No
Hand Brake:REAR WHEELS
Insurance Group 1:Not Available
Insurance Group 2:Not Available
NCAP Adult Occupant Protection %:Not Available
NCAP Child Occupant Protection %:Not Available
NCAP Overall Rating - Effective February 09:Not Available
NCAP Overall Rating - LCV:Not Available
NCAP Pedestrian Protection %:Not Available
NCAP Safety Assist %:Not Available
Rear Brakes:VENTILATED DISCS
Rear Suspension:LEAF SPRINGS
Relative Height:H2
Relative Length:L2
Running Cost League Headings:LARGE
Service Interval Frequency - Months:24
Service Interval Mileage:50000
Special Edition:No
Special Order:No
Standard manufacturers warranty - Mileage:100000
Standard manufacturers warranty - Years:3
Steering:PAS RACK AND PINION
This vehicle is classed as a car for VED purposes:No
Timing Belt Interval Frequency - Months:Not Available
Timing Belt Interval Mileage:Not Available
Vehicle Homologation Class:N1
Vin/Frame No.:Not Available
BHP:190
Engine Power KW:140
Engine Torque LBS.FT:162
Engine Torque MKG:22.4
Engine Torque NM:220
Emissions Test Cycle:WLTP
RDE Certification Level:Not Available
Alloys?:No
Automatic Clutch:Yes
Plated 3rd Axle:Not Available
Plated 4th Axle:Not Available
Space Saver?:No
Tyre Make:Not Available
Tyre Size Front:195/75 R16
Tyre Size Rear:195/75 R16
Tyre Size Spare:TYRE REPAIR KIT
Wheel Style:Not Available
Wheel Type:16" STEEL
Height:2653
Length:5709
Load Height:1900
Load Length:3130
Load Space Width Between Wheel Arches:1317
Load Width:1740
Lower Rear Door Width:1530
Rear Door Height:1450
Rear Overhang:1141
Side Load Door Height:1425
Side Load Door Width:1260
Turning Circle - Kerb to Kerb:12.8
Upper Rear Door Width:1530
Wheelbase:3520
Width (excluding mirrors):2052
Boot Capacity Saloons:Not Available
Fuel Tank Capacity (Litres):Not Available
Gross Vehicle Weight:3500
Load Space Volume:10.8
Luggage Capacity (Seats Down):Not Available
Luggage Capacity (Seats Up):Not Available
Luggage Capacity - 2nd Row Seats Removed:Not Available
Luggage Capacity - 2nd Row Seats Up:Not Available
Luggage Capacity - 3rd Row Seats Down:Not Available
Luggage Capacity - 3rd Row Seats Removed:Not Available
Luggage Capacity - 3rd Row Seats Up:Not Available
Max. Towing Weight - Braked:3500
Max. Towing Weight - Unbraked:750
Minimum Kerbweight:2514
No. of Seats:3
Payload:986
Plated 2nd Axle:2240
Plated Front Axle:1900
The improved IVECO Daily LCV is now much better equipped to take on tough rivals in the large panel van segment. Jonathan Crouch checks it out
All commercial vehicles claim to be tough and workmanlike, but here's one that can hardly be anything but. The IVECO Daily's heavy commercial ancestry gives it a capable, unbreakable feel that sets it apart in the big Transit-class market for large LCVs. Now that the Italian brand has also matched this with more efficient engines and a smarter, more car-like cabin, the Daily can appeal to a wider cross-section of business buyers than ever before.
Want a job doing properly? Then call in a specialist. It's a maxim that most business people apply to every area of their activities - except when it comes to buying a van. They'll normally select one from a brand primarily focused on selling cars, a maker with technology stretched to also include a few LCVs in its line-up. IVECO has a rather different approach. Not only does the Italian brand only make commercial vehicles but their speciality is in rather large ones. Which means that when a brand like this turns its attention to creating a van, you can expect truck toughness, business focus and a set of wheels purpose-built for the job in hand. You can, in short, expect something like this, the IVECO Daily. And the facts fit the marketing rhetoric. In an LCV market where vans are increasingly car-derived, the Daily's different, with a truck-derived chassis of unrivalled strength, versatility and durability. Which is why it was the first vehicle in its class to offer a load volume of as much as 17.2m3 and a gross vehicle weight as heavy as 7 tonnes. As a result, this Daily may reckon itself to be tougher than its large Transit-class rivals but it's also traditionally been seen as utilitarian and inefficient beneath the bonnet. IVECO takes issue with this and claims to have proved its point by creating a version of this van that's smart as well as strong, tactile as well as tough, frugal as well as fit for purpose. Let's put it to the test.
Truck-like toughness sounds good on the balance sheet, but doesn't hold much appeal if it comes with a van you've to drive long distances in or hurry through a set of twisties on the way to a short notice appointment. So how will this Daily van fare given its truck-tailored underpinnings? Better than I was expecting it to if I'm honest. Thanks to a high seating position and monster wing mirrors, it's an easy van to drive, especially round town where the light steering facilitates a tight 11.5m kerb-to-kerb turning circle (or 12.4m wall-to-wall). And under the bonnet? Well, most Daily customers will opt for the 2.3-litre F1A diesel option, offered with power ratings ranging between 116 to 156hp. Enough to tow a braked trailer of between 2800kg and 3500kgs, depending on the variant you choose. Not enough for the job in hand? Then you'll need the 3.0-litre heavy duty F1C Common Rail diesel, with outputs ranging between 160 and 210hp. There's also a battery-only all-electric model and a clever 'Natural Power' CNG variant. This features a 3.0-litre 136bhp engine tuned for methane power but able to run on ordinary petrol if you need it to. Transmission choice is between five and six-speed manual 'boxes or a 6-speed Agile semi-automatic transmission for urban-based users. Ride quality will depend to a great extent upon your choice between three different suspension systems which can be hung from the rear axle - parabolic, semi-elliptical and air. Recent camera safety feature additions include autonomous braking (IVECO's 'Advanced Emergency Braking' and 'City Brake PRO' set-ups). Plus there's Adaptive Cruise Control, which can be combined with a 'Queue Assist' system which helps the van drive itself in urban traffic. Highway use is aided by 'ProActive Lane Keeping Assist' and 'Crosswind Assist'.
The Daily has always been a tough customer. These days though, it's also usefully softer around the edges - or so IVECO hopes. You'd not miss the Italian brand's ownership of this design, emblazoned as it is across the nose of this LCV just above this model's recently redesigned front grille. The new LED lights don't need changing for the entire lifespan of the vehicle. And inside? Well the interior still can't live with the best panel vans in terms of aesthetics and build quality but the gap to the class leaders has narrowed substantially following a whole series of recent improvements that suggest the Italian brand to be finally getting to grips with the need of drivers, as well as the operators that pay them. There's now a TFT high-resolution colour display and a HI-Connect infotainment system with a 7-inch centre-dash screen, voice recognition and 'Apple CarPlay' / 'Android Auto' smartphone-mirroring. As usual with a van of this kind, you sit high up, with commanding all-round vision further aided in this case by the huge door mirrors with their useful lower wide-angle section. Despite liberal use of Fiat switchgear and instrumentation around the dash, there's nothing particularly car-like about it but at least everything feels built to last. There's also plenty of storage provision and the steering wheel now adjusts for reach as well as height.
When it comes to panel van purchase, most Daily models retail somewhere in the £30,000 to £40,000 bracket, depending on spec. That's a little more than most rivals will charge, but then you pay for toughness and quality. Panel vans will be our focus here, though as usual with this type of vehicle, a wide range of other body derivatives can be ordered if you want them, including a chassis cab (which can be ordered with a dropside body and space for crew if needed). And minibus derivatives with space for up to fifteen people if required. In choosing your Daily, first you've to decide how heavy your loads are likely to be and then choose your gross vehicle weight from three different classes designated 'L' (Light - under 3.5 tonnes in Gross Vehicle Weight), 'S' (Single Wheel and 3.5 tonnes in weight) and 'C' (Classic - the heavy double-wheel variety with weights of 3.5 tonnes or over). There's a single 2.9-tonne option in the 'L' class, then a 3.5 tonne model in the 'S' class. Beyond that, there are five different GVW options - 3.5, 4.0, 5..0, 6.5 and 7.0 tonnes - in the heavy double-wheeled 'C' class. Payload capacities range from as little as 1,185kg to well over 4,000kg in the heftiest top '70C' model and will have a big impact on which of the three suspension set-ups you order - parabolic, semi-elliptical or air. Beyond that, you've to decide whether you want extra space for crew (catered for by the Crew Van line-up), then select between three body heights, three wheelbases and four veicles lengths that will determine a cargo capacity that can be anything from 7 to 17.2m3. That only leaves manual or Agile automatic transmission, the selection between two or four-wheel drive and a choice between three trim levels.
Most of what you want to load inside should go in quite easily. There's a rear cargo door width of 1540mm and a rear cargo door height that ranges from 1430mm to as much as 1990mm, depending on your choice between three different roof heights. Whichever Daily model you choose, you'll find that it'll give you 1800mm of loadspace width that narrows to 1320mm between the wheelarches in most variants (though in a few derivatives, it can be as little as 1030mm). Enough though for the usual Europallet to slide through. Loadspace length will depend on your selection between three different wheelbases and four different body lengths. Depending on your choice, cargo capacity can be anything from 7.0 to 17.0m3. And if all that space encourages you to carry heavier loads, then you'll need to have selected a model with the right payload capacity - it can be anything from as little as 1,185kg to well over 4,000kg in the heftiest top '70C' variant. If you want to load your cargo in from the side, then there's a standard passenger-side sliding side door. As for ongoing running costs, well if you really want to get these down, then you'll want to look at the methane-fuelled 'Natural Power' model which can also run on petrol when it needs to. Or maybe even one of the clever all-electric versions. I'm assuming though, that most customers will go the more conventional route and choose something from the more conventional 2.3 or the 3.0-litre diesel line-up. Either way here, with a bit of right foot restraint, you should be able to average over 30mpg on a regular basis, thanks to features like a Stop&Start system. As for service intervals, well on the Daily they're set at 25,000 miles and all models get three years unlimited mileage cover as standard.
If you need an ordinary van that can take big loads, there are plenty of large LCVs out there that fit the bill. But what if you want something more than that? Something designed just like a fully-fledged heavy commercial vehicle but lighter, more efficient and shaped to compete with the best in the large van market. A serious tool for the serious jobs you have in mind. That's when you'd turn to this IVECO Daily van. In the past, you might have done so, then begun to wonder at the creaky HGV-inspired interior and the rudimentary road manners. But both are issues now fully sorted in this much improved model. Powerful, ecological and reliable, it remains tough enough to make some of its Transit-class rivals seem a little lightweight. It also offers the widest powertrain choice in the market and an unsurpassed load-lugging capacity. But now as well as all that, there's a little more polish, a little more finesse in the more efficient, cost-effective way it goes about its business. There are still, it's true, smarter, sharper-to-drive choices you could make in this segment and if you're an owner-driver, you might be tempted to make them. Well-informed operators though, will find today's Daily a hard van to ignore, so thoroughly designed around their needs has it been. A van from a brand with a total commercial vehicle remit. And a brand that like you, is completely focused on just one thing: getting the job done right.
